Key Features

  • High-sensitivity, high signal-to-noise ratio CMOS image sensor
  • Maximum resolution up to 8 megapixels, with a maximum resolution of 3840x2160
  • H.265 compression algorithm effectively reduces network bandwidth usage; supports dual-streaming and mobile monitoring
  • Supports various network protocols, including TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP, and RTSP.
  • Supports ONVIF protocol
  • Supports the manufacturer's dynamic domain name and third-party dynamic domain name resolution
  • Supports sending alarm snapshots via email
  • Supports uploading alarm snapshots and videos to an FTP server
  • Supports scheduled image snapshots to an FTP server
  • Supports both static IP and dynamic IP (DHCP)
  • Supports P2P plug and play
  • Compatible with browsers such as IE, Edge, Chrome, Firefox, Safari
  • Supports up to 6 users viewing simultaneously (each stream supports 3 users)
  • Provides motion detection alarm function (configurable area and sensitivity)
  • Supports human, vehicle, and pet recognition
  • Supports up to 256GB MicroSD card



Software feature:

  • Microseven camera web UI
  • RTSP - HTTP://[camera_user:camera_password@][camera_ip]:[rtsp_port]/11 -> Ultra HD 4K 3840x2160
  • RTSP - HTTP://[camera_user:camera_password@][camera_ip]:[rtsp_port]/12 -> HD 1280x720
  • Microseven software, local, and microseven.com cloud for remote management
  • Microseven live streaming via Microseven.com - Live
  • We have CGI ready and support for the camera

Here is a demo to showcase the quality of the live video stream:



Tech Specs

Model M7B4K-PSAA
SKU 018406662791
Resolution 3840 x 2160
Image Sensor 1/2.8” IMX415 CMOS
Lens M12, 2.8mm HD Lens, F=1.6
Video Compression H.264 / H.265
Audio Compression G711
Wired Connection RJ45 Ethernet Port
Wireless Connection N/A
Storage Options microSD Card (8GB ~ 256GB), FTP, NVR, NAS, Microseven Cloud
Access Protocol ONVIF
Audio Communication Two-Way Audio
Management Local & Remote
Smart Detection Motion, Human, Vehicle, Pet
Alarm Notification Mobile Push Notifications, Email Alerts
Waterproof Rating IP66
Rated Input 12V DC / 1A
Power Supply Power Adapter or POE (802.3af/at)
Power Consumption 8W
Operating Temperature -10°C ~ 60°C / 14°F ~ 140°F
Operating Humidity 0 ~ 90% RH
IR LEDs 18 Bulbs
Night Vision Infrared Night Vision

Description

The 4K low-light camera features a highly integrated SoC processor, offering ultra-low power consumption and exceptional stability. It supports the H.265 compression algorithm, which ensures image quality while effectively reducing network bandwidth usage. With powerful network capabilities, it supports the standard ONVIF protocol, RTSP, and functions like alarm image uploads to FTP servers and alarm images sent via E-Mail. Remote monitoring via mobile phones is also supported.



4K Ultra HD Quality – Upgraded to 8 Megapixels for Finer, Clearer Detail

With an 8MP camera and resolution up to 3840x2160, paired with an f/1.6 large aperture lens, it delivers 4K Ultra HD quality. Images remain sharp and detailed even when zoomed in, revealing more subtle features.



HDR High Dynamic Range – Balanced Exposure, Enhanced Detail

Enabling HDR video ensures bright areas aren't overexposed and dark areas retain more details. Even in backlit conditions, the image remains clear, realistic, and natural.



IP66 Weatherproof Design – Built for Outdoor Use

Specifically designed for outdoor environments, the camera features an IP66 dustproof and waterproof rating. It remains reliably operational in wind, sand, rain, or snow.



Human/Vehicle/Pet Detection – Smart Alerts via Microseven App with Cloud Recording

When a person, vehicle, or pet appears within the monitoring area, the Microseven App sends an immediate alert and records video, keeping your property protected at all times.



POE Power Supply – Easier Installation

Supports Power over Ethernet (PoE), eliminating the need for separate power sources, simplifying installation.



Wired Connection Support – Stable Data Transmission

In scenarios with long distances or signal interference, a wired connection ensures stable data transmission.



Two-Way Audio – Hear and Speak Clearly Outdoors

Equipped with a high-sensitivity microphone and a high-power speaker, along with a 3D noise reduction algorithm, the camera captures sound from farther away and delivers loud, clear audio—even in complex outdoor environments.



Multi-Device Viewing – Never Miss Critical Info

Supports viewing on PC, smartphone, tablet, and Alexa Echo Show, offering multiple viewing options.



Streaming Support – Compatible with Major Platforms

Supports Microseven Live, YouTube Live, Facebook Live, and other general live streaming platforms.



Multiple Storage Options – Efficient and Secure

Supports storage via microSD card, PC, NVR, FTP, and NAS.
With Microseven Cloud services enabled, alarm videos can be stored in the cloud.



H.265 Encoding – Smoother Video, Lighter Load

Saves storage and bandwidth while providing smoother video playback. Reduces bandwidth and storage usage by 50%.



Flexible Installation – Ceiling Mount, Wall Mount, and More

Supports various outdoor installation methods including ceiling and side mounting.
