| Type |
Color |
| Signal System |
PAL |
NTSC |
| Pick Up Device |
1/3" SONY Super-HAD CCD |
| Picture Elements |
512(H)X582(V) |
| Resolution |
480TV Lines |
| Mini Illumination(F1.0 30IRE) |
0Lux |
| Scanning System |
2:1 Interlace |
| Sync System |
Internal |
| S/N Ratio |
more than 50dB |
| Electronic Shutter |
AES:1/50-1/10,000SEC |
AES: 1/60-1/10,000SEC |
| Black light compensation |
ON or OFF |
| Gain Control |
Auto |
| White Balance |
Auto |
| Lens Focus |
6mm |
| Video output |
1.0Vp-p(75Ω BNC) |
| Power supply |
DC12V |
| Power Consumption |
350mA |
| Dimensionφ x H(mm) |
120×90 |
| Weight |
305g |
| Storage Temperature |
-30～+60℃ |
| Operating Temperature |
-10～+45℃ |
Power supply 12V DC 1A sold separately!
